8 Spindle Multi Head CNC Wood Carving Machine

What is the 8 Spindle Multi Head CNC Wood Carving Machine?

8 Spindle Multi Head CNC Wood Carving Machine is specially designed for customers with batch production needs. 8 spindles work together to process 8 products at one time. It is mainly used in the furniture industry, decoration industry, musical instrument industry, mold industry, crafts industry, building model industry, advertising industry, etc.

8 Spindle Multi Head CNC Wood Carving Machine8 Spindle Multi Head CNC Wood Carving Machine

The Excellent Configuration

  • Eight pieces water cooling spindles are mounted on a bracket and the distance between each pair is 250mm.
  • Big torque water cooling spindle is ideal for wood carving jobs since the carving jobs always take very long time to finish; while water cooling is better on cooled effect than air cooling in long time run.
  • The Z-axis is driven by a hardened Taiwan rolling antibacklash ball screw. And it is adopted AC servo motor with holding brake. Perfect coupler connection between ball screw shaft and driving motor shaft allows Z axis run in long term without trouble.
  • The Z-axis has a dual pneumatic counter-balance cylinder to allow very fast and accurate Z-axis positioning.
  • The machine base is welded by the thick-wall square tubes, and then precision milled by the CNC metal processing center, which guarantees the assembly accuracy from the beginning of production.
  • The upright structure adopted in the side plate has stronger rigidity and higher machine precision.
  • The whole machine is equipped with YASKAWA AC servo motors; Fast and precise. The Y-axis uses a dual drive, one for each side of the gantry.
  • Emergency stop switches are installed on both sides of the beam; if an emergency occurs, the operator can stop the machine in the shortest time.
  • To achieve the best reliability, each electro-spindle is controlled with an individual inverter. So, there are eight pieces totally.
  • All the linear guides are centrally lubricated from a central system. The lubricator is the auto type. We can set automatic timing lubrication.
  • The cable behind the machine beam adopts a plug-and-play design, which facilitates the disassembly and assembly of the beam.
  • The X and Y axis motion is via a helical rack and pinion drive, which is hardened for extremely long life and ground for a very good accuracy.

Summary

This is a multi-spindle cnc wood carving machine, also known as multi spindles cnc router (since someone would consider the spindle as head). It is equipped with a total of 8 spindle motors; This ingenious design opens a lot of possibilities for productivity (In terms of this point, we will elaborate in the following paragraphs), which is ideal for mass relief sculpture carving works in wood. So, it is usually applied to the production of solid wood European style furniture. 8 spindle cnc wood carving machine for sale with good price and excellent expert service here.

Application

Applicable Industry of 8 Spindle CNC Wood Carving Machine

It is ideal for mass wood carving jobs in furniture production. It is always applied to furniture plants, especially the one who makes European style furniture.

Materials: Good for all kinds of wood including Solid Wood and MDF.
