MOPA 200w 300w 500w Laser Cleaning Rust Removal Machine



A pulse laser cleaning machine is a type of laser cleaning system that uses a high-intensity laser beam to remove rust, paint, and other contaminants from surfaces. A portable rust removal machine is a type of pulse laser cleaning machine that can be easily moved around and used in different locations.

Category: Laser Machine>>MOPA Laser Cleaner
Response time: Within 1 hour
Supply Ability: 300 sets/month

Get Latest Price:

Description

MOPA Laser Cleaning Machine

One of the advantages of the MOPA laser cleaning machine is that it allows the user to adjust the pulse duration, frequency, and power of the laser beam, which makes it possible to tailor the cleaning process to the specific requirements of the application. This flexibility is particularly useful when dealing with delicate or sensitive materials, as it allows the user to select the optimal settings to avoid damage to the material.

The pulse laser cleaning machine uses short pulses of laser light to create a shock wave on the surface of the material being cleaned. This shock wave removes the contaminants without damaging the underlying material. The process is fast, efficient, and environmentally friendly, as it does not require the use of chemicals or abrasive materials.

rust removal machine 500w rust cleaning laser

MOPA(200w/300w/500w)Pulse Laser Cleaning Machine

Trolley Box MOPA Laser Cleaning Machine

handheld laser cleaning machine for rust removal

Hand cleaning head

Small and light, different cleaning modes, multi-system compatible.

Fiber laser

Stable performance, low energy consumption, low failure rate, flexible optical fiber 5-20m, flexible and convenient, can achieve outdoor work, and has a rigid protective layer.

Wire spool

Wire spool

The standard cable is 10 meters, and the winding tray is used to comb the cable to avoid entanglement affecting the work.

Touch screen panel

Touch screen panel

Friendly interface; Rich functions, a variety of cleaning modes are optional, easy to learn.


IGCL-MOPA Laser Cleaning Machine Parameter

Technical Parameters

Service voltage Single-phase 220V±10%, 50/60Hz AC
Overall power consumption <4800W
Operating temperature 5℃~40℃
Operating humidity ≤80%
Laser power 200W/300W/500W
Laser power instability <2%
Laser type Pulse
Pulse width 2-500ns adjustable
Max. monopulse energy 2mJ
Optical quality(M2) <1.8
Controlling power range(%) 0-100(Gradient adjustable)
Frequency adjustment range(kHz) 1-4000kHz(Gradient adjustable)
Fiber length 5m
Type of cooling 200W/300W air-cooled, 500W water-cooled
Scanned area 0.01~350mm
Scanning speed 0~60000mm/s
Field lens focal length(mm) 240mm
Cleaning mode 8 kinds
Machine size (L*W*H) 1160mm*600mm*1150mm
Total weight 165KG
Cleaning head weight 1.4KG
Operating mode Handheld

Laser Cleaning Machine Advanced Performance:

  • Non-contact cleaning, do not damage parts matrix;
  • Precision cleaning, can realize the precise location, accurate size selective cleaning; High cleaning efficiency, save time; u
  • Don’t need to use any chemicals and cleaning fluid, basic for solid waste powder after cleaning, small volume, easy to store, can easily solve the problem of chemical cleaning;
  • Simple operation, can be hand-held or cooperate with manipulator automation cleaning;
  • Of human body engineering design, the operation labor intensity is greatly reduced;
  • Laser cleaning system is stable and almost no maintenance;

Laser Cleaning Machine Application


> Rust removal on metal surface;> Surface paint removal treatment;

> Surface resin, oil, stains, dirt cleaning;> Surface coating, coating removal;

>Pretreatment of welding surface/spraying surface;> Removal of dust and attachments on the surface of stone statues;

> Rubber mold residue cleaning.

Derusting parts
rust remover for cars

MOPA Laser Cleaning Machine

The MOPA laser cleaning machine is a type of laser cleaning system that uses a MOPA (Master Oscillator Power Amplifier) laser source. MOPA lasers are known for their versatility and flexibility, which makes them suitable for a wide range of applications, including cleaning, marking, engraving, and welding.

One of the advantages of using a MOPA laser cleaning machine is its ability to perform non-contact cleaning, which minimizes the risk of damage to the surface being cleaned. Additionally, laser cleaning is an environmentally friendly process, as it does not involve the use of chemicals or solvents, which can be harmful to the environment and pose health risks to workers.

Overall, a MOPA laser cleaning machine is a powerful and versatile tool that offers a fast, efficient, and environmentally friendly way to clean a wide range of materials in industrial applications.
