Advantages of CNC milling machine
Although there are different CNC systems for various types of CNC milling machines, but the Advantages of CNC milling machine are basically the same except for some special functions.
1. Point control function
This function can realize the machining of hole series with high requirements for mutual position accuracy.
2. Continuous contour control function
This function can realize the interpolation function of straight line and arc and the processing of non-circular curve.
3. Tool radius compensation function
This function can be programmed according to the size marked on the part drawing without considering the actual radius of the tool used, thereby reducing the complex numerical calculations during programming.
4. Tool length compensation function
This function can automatically compensate the length of the tool to meet the requirements of tool length adjustment in machining.
5. Scale and mirror processing function
The scale function can change the coordinate value according to the specified scale to execute the edited processing program. If the shape of the part is symmetrical about the coordinate axis, only one or two quadrants need to be programmed, and the contours of the remaining quadrants can be realized by mirroring.
6. Rotation function
This function can execute the edited processing program by rotating it at any angle in the processing plane.
