cnc stone marble cutting and polishing machine
CNC stone cutting machine for sale
cnc stone marble cutting and polishing machine
5 Axis Bridge Saw Stone Cutting Machine

CNC Granite & Stone Cutting Machine for Sale

CNC stone/marble cutting and polishing machine based on CNC Computer Numerical Control combine with powerful water cooling spindle to make a perfect work on stone. Surface engraving or 3D carving are all available. With this machine, anyone could be an artist.

CNC stone,Marble,granite cutting machine designed for cabinets artificial stone, quartz stone, granite, marble, carving, cutting, polishing, drilling, engraving.

Category: CNC Router>>Stone Cutting Machine
Response time: Within 1 hour
Supply Ability: 300 sets/month
Price Range: $10000-$16000

Get Latest Price:

Description

CNC Saw Stone Marble Cutting Machine Granite Cutting Tools

The 5-Axis CNC Saw powered up with 4000W motor, it cuts the hardest slabs such as porcelain, ultra-compact materials, and quartzite with ease.Bridge cutting machine is suitable both for small and big factory. This machine is good for cutting marble and granite in a manual or automatic way.

Best Granite CNC Machine for sale

The CNC 5 axis bridge cutting machine is a cost-effective stone processing machine tailor-made for the majority of stone companies in order to meet the diversified processing needs of the market. This 5 axis granite cutting machine is a multifunctional CNC stone router machine, it can process almost all stone. As a 5 axis stone cutting machine, it come with Five-axis cnc bridge saw, which support tool tip follow RTCP, high precision and easy to learn and understand. More over it can complete 5D plane And 3D carving. You only need to buy this 5 axis marble cutting machine to complete almost all the tasks required by small processing plants.

cnc stone marble cutting and polishing machine

CNC stone cutting machine

Easy to switch between cutting polishing and drilling

The machine head automatically flips ±360 degrees

Infrared Localization,convenient to observe and adjust

5 axis stone CNC machine_18

Independent research and development -iGOLDEN control system


Infrared Localization

CNC Granite Machine is orthogonal cutting mode allows operators to cut manually in any direction at any desired angle, with a laser line to guide these simple manual cuts without generating a program. Positioning of the machine is controlled by manual joysticks on the HMI or a wireless pendant.

5 axis stone CNC machine_18

CNC Stone Router Machine Technical parameters:

Programming method 1 Manual programming
Programming method 2 Image input
Control method CNC
Power 4000W
Working voltage 380V/50HZ
R.P.M 2800r/min
Blade size 350mm
X-axis working stroke 3000mm
Y-axis working stroke 2000mm
Z-axis working stroke 260mm
A-axis working stroke

360°free rotation

X/Y-axis cutting speed 1-2000mm/min
Z-axis cutting speed 1-1000mm/min
A cutting speed 0-7r/min
Cutting thickness 100mm
Processing precision 0.2mm
Working table size 3000*2000mm
Overall size 4500*2750*2100mm
Weight: 2000KG




CNC granite cutting machine for sale

The stone bridge cutting machine can realize cutting, chamfering, edging, profiling, milling, drilling, slotting, rounding, circular arc and other special-shaped processing through five-axis linkage. It is simple to operate and has strong practicability. A variety of configurations are available.

1.Rotatable Work Table And 5 Axis CNC Bridge Saw Of Stone CNC Machine

2.Vacuum Adsorption And 1/2″ Threaded Interface

3.Moving Camera And Comprehensive Stone Cutting Function

4.The machine head automatically flips ±360 degrees Infrared

5.Localization,convenient to observe and adjust


CNC Marble Cutting Machine

The 5 axis CNC stone bridge saw cutting machine is good at cutting, milling, chamfering and edging quartz, marble, artificial stone and slabs in regular and irregular shapes. It can realize countertop cutting, bridge cutting, roman column cutting, arc line cutting, concave-convex cutting, and irregular edge cutting and milling. The automatic stone cutting bridge saw can process products of sanitary ware, stone furniture, interior decoration, and other fields. For example, wash basins, bathroom countertop, stone tables, dinning tables, kitchen tables, kitchen cabinet basins, background wall, roman edge stone decorations, etc.

Automatic Rounding

Sink Processing

Marble Carving

Furniture Decoration

Stone machine processing

Marble Cutting

Jade Making

Furniture Decoration Making


iGOLDENCNC, Your best choice

Becoming a customer of iGOLDENCNC, we will cooperate with you on the basis of complete trust and comfort. You will find that we are a reputable supplier and worth your trust. We understand that every customer is valuable, and we will cherish every opportunity to cooperate!

Strict Quality Control System

Advanced testing equipment are used, such as: dynamic balance tester, CNC high precision machining machine, 3D measuring machine; iGOLDENCNC has established a complete and strict quality control system, including 48-hour running test and 72-hour aging test, to ensure the excellent quality of our machines.

FAQ

iGS-B is a 5-axis CNC Saw, with the ability to move the X, Y, and Z linear axis and rotate the A and C axis; reducing overall program cycle times. This design also allows for: continuous arc blade cutting, incremental routing, straight line profiling, faucet coring, 0-90° mitering and more, making it an extremely versatile machine.

Yes, the worktable of this machine can flip up to 80 degrees to facilitate the unloading of stone slabs. It also improves work efficiency and saves human labor.

CNC bridge saw is an advanced CNC cutting machine, it takes diamond blade as cutting tool and is controlled by 5-axis linkage system, namely, 3 straight moving axes and 2 rotation axes. Different processing functions are available including cutting, polishing, drilling, engraving, etc. The CNC bridge saw has much advantages of high automation, easy operation and advanced functions, it greatly improves the working efficiency and processing accuracy, thus is an indispensable equipment for stone processing industry.

The cost of marble CNC machine is closely related to the actual machine type and its configuration. Different kinds of granite CNC machines are available such as marble engraving machine, stone cnc machining center, 5 axis cnc bridge saw, etc. Though of similar appearance, their functions & structures vary much. Also, the actual configuration of those granite cnc machines are quite different, important parts that matter include HSD spindle, servo motors, drivers, CNC system, software, guide rails, rack pinon, etc. Besides, some other factors will have to be taken into consideration for overseas buyers, including tax, customs clearance, shipping fee, etc. In general, market price of the marble cnc machine ranges from $ 5,000 to $ 100,000, depending on the actual type and the specific configuration of the marble machines.

The main function is plane carving , relief, line carving, cutting, lettering, hollowing, chamfering, drilling, etc..
