What laser can Stainless steel and wood?

The multi-function laser cutting head is suitable for cutting metal and non-metal materials. The fixed optical path compensation system ensures the consistency of the laser spot quality in the entire cutting area.

The laser engraving machine can improve the efficiency of engraving, make the surface of the engraved place smooth and round, quickly reduce the temperature of the engraved non-metallic material, and reduce the deformation and internal stress of the engraved object; it can be divided into non-metallic according to the different laser light sources Laser engraving machine and mixed cutting engraving machine. Co2 non-metal laser engraving machines generally use glass laser tubes in China, and some high-end laser engraving machines use co2 metal radio frequency tubes.

laser metal engraving machine

Fiber lasers achieve high cutting speeds in thin material thicknesses. Additionally they boast low power consumption while requiring little maintenance. The special properties of this laser cutting technology enable applications in steel, stainless steel, aluminum, and non-ferrous metals, such as copper and brass.

CO2 lasers are characterized by their high cutting quality. Their primary area of application lies in the medium to high range of material thicknesses. The cutting edges achieved with the laser beam excel through burr-free cutting and low scoring. This means that the cut parts can be processed further without reworking.

The carbon dioxide laser is a gas molecular laser, the working substance is CO2 gas, and the auxiliary gas is nitrogen, helium, xenon and hydrogen. Since the energy conversion efficiency of this laser is as high as 25%, it is often used as a laser with high power output. The wavelength of carbon dioxide laser is 10.6 microns. It is impossible to see infrared light, has good stability, and is widely used.

Laser Engraver Machine Parameter

Model iGR-BM-1325
Working size 1300*2500mm
Laser type Sealed CO2 laser tube(RECI Brand)
Laser power W6 130W RECI laser tube
Cutting speed 0-3,000mm/min due to different material
Position accuracy ±0.05mm
Work platform Stainless sheet and knife table
Operating temperature 0-45 degree
Transmission High precision ball-screw system
Minimum shaping character English 1*1mm
Graphic format supported BMP, PLT, DST, DXF, and AI
Driving system stepper motor
Cooling mode Industrial Chiller
Auxiliary equipment Exhaust-fan, air-exhaust pipe
Controlling software Off-computer controlling system
Compatible software Coreldraw AutoCAD Photoshop
Working voltage AC110-220V ±10%/10A,50-60HZ
Power <2000W
Weight 1200KGS

Applicable Industry

Engraving and cutting of paper, fabric, plastic, nonwoven cloth in garment and toy industries, also inclusive of precise cutting to non-metal materials, like acrylic and MDF board in handbag, glove, mold, advertisements, decoration, electrical appliance and plastic industries.

wood laser engraving machineacrylic laser engraving machinelaser engraving machine for metal

How is a CO2 laser engraving machine used?

CO2 laser engraving machine is widely used in a variety of non-metallic materials, such as acrylic, leather, cloth, paper, bamboo products, wood products, resin, rubber, etc. The mixed cutting machine can also be used for cutting and engraving thin metal sheets. Popular applications include:

1. Printing and packaging industry: rubber plate laser engraving, paper products laser cutting, knife template engraving, etc.

2. Craft gift industry: crystal carving, bamboo slips, bamboo mats, bamboo curtain laser hot stamping, ivory, bone, shell carving, woodblock book laser carving, mahogany laser carving, box-shaped crafts laser carving, chessboard laser carving, etc.

3. Advertising and publicity industry: large-scale blister cutting, plexiglass laser engraving (cutting), laser production of various plaques, crystal, trophy engraving, two-color plate laser engraving (cutting), metal sheet cutting.

4. Leather garment industry: cutting of all kinds of shoe materials, fur, real leather, artificial leather and surface pattern carving, cutting, hollowing; pattern cutting of all kinds of clothing, fabrics and textiles, etc.

5. Model making industry: sand table building model laser engraving (cutting) production; aviation, navigation, model laser engraving (cutting) production; cartoon character model laser engraving (cutting) production; industrial sample model laser engraving (cutting) production, etc.

6. Other industries: engraving marks on decorative materials such as marble, granite, glass, crystal, paper cutting, greeting cards and other paper craft cutting.
