CNC Wooden Door Lock Making Machine

Wooden Door Lock Hole Machine for sale

What is the Wooden Door Lock Hole Machine?

The Wooden Door Lock Hole Machine, also called wooden door lock hole machine, is specially designed for the production of wooden doors. It can not only carving the door panel, but also complete the processing of lock mortising, lock slot and lock step slot of the wooden door at one time.

CNC Wooden Door Lock Making Machine

Product Description of the Door Lock Hole Machine

Work itinerary:1300*2500*200mm, one can swing around 90 degrees

Bed body:Thick-walled Steel Pipe


Spindle:4.5KW air-cooled spindle with different power spindles available

Spindle speed:0-18000 rpm/min

Frequency converters:Fu/delta/day Care

Guide:Taiwan Upper Silver

Tooth rack:Taiwan Crescent

Motor:servo, Stepping (optional)

Driven:servo, Stepping (optional)

Gear Reduction Machine:Taiwan New Treasure (none)

XYZ structure:XY rack, Z Screw

Countertop structure:Vacuum adsorption table  Aluminum profile Table (optional)

Vacuum system:Options available

Vacuum pump:5.5KW water-cooled/5.5kw Air-Cooled

Oil injection system:Manual (automatic Optional)

Locating cylinders:No

Engraving instructions:G Code

Maximum Empty line speed:Maximum Empty line speed

Max engraving speed:20000mm/min

Operating voltage:ac220v/380v-50hz

Operating system:Weihong System/dsp/bao Yuan/shan Long

Gross weight:2500KG

Kinematic positioning accuracy:±0.05mm

Repeat positioning accuracy:±0.02mm

Three-process Lock Hole cnc router Characteristics:

1, Structural stability: Industrial production models, heavy-duty full steel structure welding, tempering vector effect treatment, strong non-deformation.

2, Parts excellent: Taiwan control system, spindle bearings for high-precision ceramic bearings, low noise, long Life.

taiwan-produced linear guide: German-made ball screw, heavy load-bearing capacity, the knife Precision.

3, Modular Structure Design: Choose to add a variety of processing spindle configuration, can be carved, hollow, cutting and milling Work.

4, complete functions: processing parts such as the need for three knives to complete, eliminating the cumbersome tool change, with the function of machining center, the middle spindle can be vertical or one-way horizontal work, in the need of side work, the middle shaft and as a horizontal axis to complete the groove, drilling Work.

5, high adhesion vacuum adsorption device, up to 230 cubic meters/hour. 6, software compatibility: Open software interface, can be compatible.

CNC Wooden Door Lock Making Machine

Three-process Lock Hole cnc router Scope of application

Wooden door plane keyhole shape of the milling Groove hole molding, can also be used for wooden doors, door frames, window frames, Casement tenon groove.
