CNC woodworking engraving machine factory direct sales

In addition to the basic functions of cutting, punching and engraving, CNC woodworking engraving machine is also favored by woodworking practitioners for its simple operation, powerful practical functions and strong practicability.

CNC Router MachineThe technical classification of CNC woodworking engraving machine can be roughly divided into three types:

  1. Stepper driver + stepper motor: The stepper system is the most used drive system on the market. The most popular is the three-phase hybrid stepper motor, which accounts for more than 90% of the market share. The reason is price. Inexpensive and works well with Lexicon segment drivers.
  2. Hybrid servo drive + motor: The use of hybrid servo has not been popularized in China. This thing is caused by many reasons. There are not many foreign manufacturers producing hybrid servos. Compared with AC servo, the price does not have much advantage, but the effect is better than AC servo. The performance is much stronger.
  3. AC servo drive + AC servo motor: The use of AC servo in engraving machines is still relatively small, mainly because the price is relatively high, and the application of AC servo must have certain requirements for structure, electrical appliances, machine tool control system and transmission. system. CNC Router Machine

CNC woodworking engraving machine factory direct sales

CNC woodworking engraving machine is roughly divided into three types, one is CNC plane engraving machine, one is multi-axis three-dimensional engraving machine, and the other is plane engraving and three-dimensional engraving. Plane engraving machines and 3D engraving machines are often used in the market. Woodworking CNC plane engraving machines also have different names such as facade engraving machines, relief engraving machines, and surface engraving machines.

In addition to understanding the engraving machine, we also need to understand the tools of the woodworking engraving machine. There are also many types of woodworking engraving machines, mainly as follows:

Flat-bottomed knife: Also known as cylindrical knife, it mainly relies on measuring knife for engraving, and the bottom edge is mainly used for plane trimming. Flat-bottomed knives are mainly used for contour cutting, plane milling, area rough engraving, surface rough engraving, etc.

Ball-end knife: The blade of the ball-end knife is curved. The engraving machine forms a hemisphere during the engraving process. During the engraving process, the force is uniform and the cutting is stable, especially suitable for curved surface engraving. It is often used for semi-fine carving and fine carving on curved surfaces. Ball cutters are not suitable for milling planes.

Bull nose knife: Bull nose knife is a hybrid of cylindrical knife and ball knife. On the one hand, it has the characteristics of a ball cutter, which can engrave curved surfaces, and on the other hand, it has the characteristics of a cylindrical cutter, which can mill planes.

Taper flat-bottomed knives: Taper knives for short, taper knives are the most widely used in the entire engraving industry. The bedknife of tapered knives, commonly known as tip, is similar to cylindrical knives and can be used for finishing facets. The side edge of the tapered knife is angled at an angle, creating a beveled edge during the engraving process. It allows it to achieve the widest range of applications in the engraving industry. The bottom edge of a tapered knife, commonly known as the tip, is similar to a cylindrical knife and can be used for finishing facets. The side edge of the tapered knife is angled at an angle, creating a beveled edge during the engraving process. So as to achieve the unique three-dimensional angle clearing effect in the engraving industry. The engraving machine cone knife is mainly used for single-line engraving, regional rough engraving, regional fine engraving, projection engraving, image grayscale engraving, etc.

Conical ball cutter: referred to as the cone ball cutter. Cone and ball knives are a mix of taper knives and ball knives. , you can engrave finer surfaces. Cone ball knives are often used in relief surface engraving, projection engraving, image relief engraving, etc.

Cone Nose Knives: Cone Nose Knives are a mix of Cone and Bull Nose Knives. On the one hand, it has the characteristics of a tapered knife, which can have a smaller tip. Engravers engrave and mill finer surfaces. The characteristics of the bull nose knife, so the conical bull nose knife is often used for relief surface carving.

Drilling tools: mainly used for drilling. When the hole is relatively shallow, it can be drilled with a flat bottom knife.

Big-end knife: It is essentially a conical knife with a relatively large head cone angle. Mainly used for three-dimensional clear angle.

The above is the classification of the general CNC woodworking engraving machine tool types. Only good tools and a good CNC woodworking engraving machine can bring out the best value.

CNC will continue to develop and develop better CNC woodworking engraving machines according to the development of the market to give back to everyone’s support. If you have any questions about woodworking machinery later, you can contact us at any time.
