Stainless Steel CNC Fiber Laser Cutting Machine

What is the fiber laser cutting machine?

The fiber laser cutting machine is a mechanical CNC laser cutter that uses a fiber laser source to output a high-energy-density laser beam, which instantly melts and vaporizes the area illuminated by the ultra-fine focus spot on the workpiece, and moves the spot irradiation position through a numerical control mechanical system, thereby achieving cutting.

Stainless steel Laser cutting stainless steel uses the energy released when the laser beam is irradiated to the surface of the steel plate to melt and evaporate the stainless steel. For the manufacturing industry that uses stainless steel sheets as the main component, laser cutting stainless steel is a fast and effective processing method. The important process parameters affecting the cutting quality of stainless steel are cutting speed, laser power, air pressure and so on. Compared with low carbon steel, the laser power and oxygen pressure required for stainless steel cutting are higher. Although stainless steel cutting achieves a satisfactory cutting effect, it is difficult to obtain a seam with no sticky residue. The method of laser beam coaxial injection blows away molten metal so that no oxide is formed on the cutting surface. This is a good method, but it is more expensive than traditional oxygen cutting. One way to replace pure nitrogen is to use filtered plant compressed air, which consists of 78% nitrogen. When laser cutting the mirror stainless steel, in order to prevent serious burns to the plate, a laser film is required!

1000w-6000w Stainless steel laser cutting machine

Fiber laser cutting machine manufacturer

IGOLDENLASER has the most powerful parts processing and manufacturing capabilities in the industry. We built dozens of large-scale processing equipment, CNC machining centers and laser collimators, laser interferometers, ballbars and other high-precision processing equipment and testing equipment. And we also adopt original imported accessories, and learn from the advantages of international equipment technology. We adhere to independent and continuous innovation, improve manufacturing levels, so that won the unanimous recognition of the market and customers.

Now IGOLDENLASER Laser exports to more than 100 countries and regions around the world relies on reliable product quality, reasonable price and perfect after-sales service system.

We are assisted by self-motivated professionals, who posses sound industry experience of their respective domains. All these experts work in sync among each other and also accomplish the assigned tasks in due time. Moreover, all our professionals are well-versed with the operating and handling knowledge of advanced machines.

IGOLDEN Laser adheres to the business philosophy of “creating a century-old laser enterprise and cultivating a professional partnership company”, constantly improving product quality, and becoming an enterprise loved by employees, trusted by customers, respected by the industry, and recognized by the society!

1.Rich industry experience. When we was a small factory, we had already put our focus on fiber laser cutting machine, which is not like some other suppliers who turned to laser market when they found the potential.

2.Separate R&D department. This means we are able to offer customized machines for our clients, cater their exclusive demands.

3.Technical supports. We have offered our machines to over 140 countries and regions, which allow us to accumulate abundant successful experience from our clients. In this way, we are able to offer all kinds technical solution and service.

4.Optimum quality. All suppliers, cooperating with us, are coming from world-class manufacturers. Each machine, before leaving for our clients, will be tested with enough time , which allows us to have a fully check on the machine.

5.Timely delivery. Each machine is arranged with precise assembly steps without any delay.

6.Good after-sales service is one of our biggest advantages , we have professional engineers, who can speak English. Online service ,phone calling and remote controlling are always used to do service for overseas clients. If necessary, engineers can be available in clients’ factory site.

7.Company value: To create value for the community with laser technology.

8.Our attitude: We are honest, professional, hardworking and eager to obtain results. We take clients as our partners.

In the future, we will adhere to the development concept of Industry 4.0, insist on making intelligentized production, making production simply, and providing better solutions for enterprise intelligence

Why choose the fiber laser cutting machine?

1. High cutting accuracy: The positioning accuracy of the metal laser cutter reaches 0.05 mm, and the repeated positioning accuracy reaches 0.03 mm.

2. Narrow slit: The width of the slit is generally 0.10-0.20 mm.

3. Smooth cutting surface: There is no burr on the cutting surface, and the roughness of the cut surface is generally controlled within Ra6.5.

4. Fast cutting speed: the cutting speed can reach 10 m / min, and the maximum positioning speed can reach 30 m / min.

5. Good cutting quality: Adopting non-contact cutting, the cutting edge is affected by heat little, there is basically no thermal deformation of the workpiece, to ensure that the workpiece is not scratched, and the slitting generally does not require secondary processing.

6. Laser processing has good flexibility: the fiber laser cutting machine can process arbitrary graphics, and it can cut pipes and other profiles without being affected by the shape of the workpiece.

Laser cutting machine  PARAMETERS

EModel iGR-E 3015 iGR-EH 3015
Working area 3050*1530mm
X axis stroke 1530mm
Y axis stroke 3050mm
Z axis stroke 315mm
Accuracy X, Y axis positioning accuracy 0.05mm 0.03mm
X, Y axis repositioning accuracy 0.03mm 0.02mm
Speed X, Y axis max. running speed 80m/min 140m/min
X, Y axis max. accelerated speed 0.8G 1.5G
Power supply Phase 3
Nominal voltage 380V
Frequency 50/60Hz
Machine body Max. working loading 500kg 800kg
Body weight 3500kg 5000kg
Size(L*W*H) 7550*2280*2000mm 7660*2280*2000mm
Laser power 1000w/ 1500w/ 2000w/ 3000w 1000w/ 2000w/ 3000w/ 4000w/ 6000w
Worktable optional 4000*2000mm/ 4000*2500mm/ 6000*2000mm 4000*2000mm/ 6000*2000mm
