4 Axis Woodworking CNC Router

The Circuit Design Of The Control System Of The 4 Axis Woodworking CNC Router

4 axis woodworking cnc router is a type of automated power machine tool with CNC controller for relief carving and sheet cutting, as well as adding the fourth axis (rotary axis) for 3D cylinders milling.. It can engrave 3D patterns and drill holes on side surfaces of wood, MDF, acrylic, foam, rubber, and other materials. For example, 3D letters, signs, reliefs, and sculptures.

4 Axis Woodworking CNC Router with Rotary AxisCNC router manufacturers conduct research on the specific components used in the control system of the 4 axis woodworking cnc router based on the overall design of the four-axis cnc router control system.

  ①The power supply adopts 220V AC power supply, and the components of the distribution box are protected by the fuse, that is, the power supply of the control system can be automatically cut off in the event of a short circuit or excessive current;

  ②The three button switches (total stop button, servo system button and computer mainframe power button) are controlled by 220V alternating current to control the total power supply, servo system power supply and PC power supply respectively, and enable different machine functions according to different processing needs;

  ③A filter is installed between the servo system button and the servo drive to prevent the entry of high-frequency noise from the external power supply, reduce the interference to the system servo, and ensure the stability of the work;

  ④Because the motion control card terminal board needs independent power supply, a 24V switching power supply is used;

  ⑤The X, Y, Z axis drivers are connected to the X, Y, Z axis interfaces of the control card terminal board, and the A axis drivers are connected to the A axis interface of the motion control card terminal board. They all have different interface terminals;

  ⑥ The spindle frequency converter is connected to the pulse interface of the control card terminal board to realize the pulse transmission to the electric spindle;

  ⑦The drive is connected to the corresponding motor, and the inverter is connected to the corresponding electric spindle;

  ⑧ The sensor is connected to the X, Y, Z axis interface of the control card terminal board to control the limit position of the machine tool. The cnc router manufacturer pointed out that the circuit can also select different components according to the accuracy requirements of different machine tools.

This rotational axis allows cuts to be executed on multiple sides of the workpiece without resetting, while a 3-axis router can only perform cuts to one side of the same piece at a time. 4 axis woodworking cnc router are the preferred method for advanced, intricate cuts and carvings like those often seen in furniture, musical instruments, cabinetry, and more.

4 Axis Woodworking CNC Router

Application Of 4 Axis Woodworking CNC Router
Application Industry
It is a cnc router for general woodworking applications engineered to make door panels, Cabinetry, Exhibits and Fixtures, furniture, woodworking projects, table or chair legs, sculptures, 3d art, interior decoration, signs, and more.

Applied Materials
Flat-working: Acrylic, MDF, ACM, Melamine, Phenolic, Plywood, HDPE, PVC, Solid Surface, Foam, Solid Wood, White expanded PVC, and more.
