wood cnc router

What is wood 3 axis,4 axis, and 5 axis CNC router

We are aware that wood design often requires multiple tools and different cut strategies for perfect wood cuts. A variety of woods are used in woodshops, as well. Woodworkers pay close attention to detail so we knew that designing woodworking specific CNC machines would require a tool changer for optimal cut quality and easy tool changes to switch between bits and grooves. Our technicians are very helpful in advising on the appropriate tooling and cut strategies for many different materials involved with woodworking. The Titan and HDS Series are a good fit if you want to cut hard woods because they are equipped with a 12 horsepower HSD brand spindle. This, combined with an all steel construction, allows for aggressive cuts and clean finishes.

Woodworkers are most interested in our ATC and Nesting CNC’s because of its tool changing capability. Woodworking often requires multiple tools and different cut strategies. A variety of woods are used and attention to detail/the right cutting tools are a few necessities for woodworking. These two CNC models were specifically designed with these requirements in mind. Our technicians are very helpful in advising on the appropriate tooling and cut strategies for many different materials involved with woodworking.

WHAT IS 3 AXIS CNC router?

The 3-axis CNC Router is the entry-level and widely applied CNC router machine. Its excellent durability and stability are praised by customers from all over the world. The 3-axis CNC wood router includes the single-spindle CNC wood router, dual-spindle CNC wood router, multi-head CNC wood router, multi-processing CNC wood router with pneumatic tool changer, CNC wood router with automatic tool changer and mini CNC router machine.

In the three-axis CNC machine, the best seller is ATC CNC router machine with automatic tool changing function; the most economical is single-spindle CNC wood router; mass production can choose multi-head CNC wood router (the most common is 1-6, 1-8 and 2-4); multi-processing CNC wood router (three processes, four processes) has the function of pneumatic tools changing, suitable for parts needing different processing technology; mini CNC router machine is widely used in advertising and small mold industry for its small volume and high accuracy.

The 3-axis CNC Router is also known as 3 axis CNC machine, 3 axis CNC router machine, 3 axis CNC milling machine, 3 axis wood CNC machine, 3 axis CNC wood router, 3 axis wood router, 3 axis mini CNC milling machine, 3 axis wood carving machine.

CNC engraving machine

WHAT IS 4 AXIS CNC router?

The 4-axis CNC Router machine refers to the computer numerical control equipment including X, Y, Z, and additional rotation axis. It has 3 straight coordinates and 1 rotating coordinate. 4-axis CNC Router engraving machines are usually equipped with rotating axes or rocking spindles, so they can contact the workpiece from different angles and effectively work, so as to realize the 3D processing of cylindrical, curved and circular surfaces.

The 4-axis CNC Router is divided into the rotary type and spindle swing type, including right rotary axis engraving machine (customizable front rotary device), 2D&3D CNC engraving machine, 3D stereoscopic engraving machine, four-axis CNC machining center, foam carving machine, spindle swing engraving machine, and lock hole machine.

The 4-axis CNC Router is also known as 4-axis CNC wood router, 4-axis CNC router machine, best -axis CNC router, 4-axis CNC milling machine, 4-axis CNC machine, 4-axis milling machine, 4-axis CNC engraving machine, 4-axis CNC router engraver machine, 4th axis CNC router, 4-axis machining, 4-axis engraving machine, 4-axis wood CNC machine, 4-axis wood carving machine.

WHAT IS 5 AXIS CNC router?

The 5 axis CNC Router machine, also known as the 5 axis CNC machining center, is equipped with a 3D CNC system. It is designed as a 5 axis CNC processing solution with high cost-effectiveness. It refers to the ability of the machine to move tools or parts on five different axes to achieve complex surface processing.

The basic processing is carried out on three axes of X, Y, and Z, but the 5 axis CNC processing tool can rotate the additional two axes A and B forward. These additional axes can shorten the processing time because they can cut five edges of the material at the same time. This provides a multi-directional solution for cutting tools. However, because of the longer X-axis of the 5 axis machine tool, the stability and accuracy are low. This may require more attention than the 3 axis or 4 axis CNC router machine.

The 5 axis CNC machine tool is also known as the 5 axis CNC milling machine, 5 axis CNC machining center, 5 axis CNC carving machine, or the multi-axis machining center.

How is a CNC Router used?

Furniture industry: processing of all kinds of cabinets, cabinet doors, chairs and tables, and the overall customization of kitchen and bathroom.

Decoration industry: PCB, PVC, MDF, stone, plexiglass, copper and aluminum and other soft metal processing; Precision Industry: cutting large 3D(three-dimensional) parts in the automotive, aerospace and ship industries;

Mold industry: mold, foam mold, car models, train models, aviation models, ship models, paraffin mold, and other large non-metal molds.

What’s the worktable size of the CNC Router?

4×4, 4×6, 4×8, 6×9, 5×10, 6×12, 10*13, 10*16 in feet; 48×48, 48×72, 48×96, 72×108, 60×120, 72×144, 120×156, 120×190 in inch; 1212, 1220, 1325, 2030, 2040, 3040 and 3050 in milometer. Of course, the worktable size can be customized as your requirements.
