Tube & Sheet Laser Metal Cutting and Engraving Machine



This fiber laser cutting sheet metal machine is a multifunctional optical fiber cutting machine.It can not only cut metal plates but also tube pipe. This allows you to engage in sheet manufacturing and tube manufacturing industries, and you don’t need to buy two separate laser cutting machines. This CNC laser metal cut pipe laser cutting machine can reduce your investment cost and floor space Meanwhile it will bring you higher production efficiency.

Category: Laser Machine>>Laser Cutters
Supply Ability: 200 sets/month
Price Range: $4850-$163500

Get Latest Price:

Description

Tube & Sheet Metal Laser Cutter iGR-FH(+T)

iGR-FH(+T) can process both metal sheets and metal tubes, which greatly saves the purchase cost and space. The length of the tube can be selected from 3m or 6m,The machine adopts heavy-duty cast iron bed which will not deform within 20 years. And the equipped aviation aluminum beam runs stably. What’s more, the fully automatic dual-start chuck is strong and durable. Besides, the machine is equipped with imported transmission components which have high precision.

tube laser cutting machine

Tube and Plate Fiber Laser Cutting Machine

This metal sheet and tube fiber laser cutter is the best choice for processing complex metal pieces. It can not only process metal sheets with fast speed and good accuracy, but also process metal tubes and make precise cuts. DXTECH equips this metal sheet and tube laser cutter with world-class components, such as Raycus/Max laser source, Japan Yaskawa/Fuji servo motor, Taiwan HIWIN/PMI guide rail, France Schneider electronic components, etc. The working size and laser power can be customized according to the customer needs. This machine has wide applications in auto parts, robot parts, rocket parts, aircraft parts, ship parts, household appliance parts, metal tools, engineering machinery parts, agricultural machinery parts, metal decoration, metal furniture, kitchen countertop, kitchenware, and fitness equipment industries.


Sheet Tube Laser Metal Cutting Machine advantages

1. One machine for two purposes
Double-use function saves both cost and space. It can not only process metal sheets, but also various metal tubes, which greatly improves the work efficiency.
2. The strong steel bed to keep the machine for many years without distortion.
3. World-class components like guide rails and racks to guarantee the cutting accuracy.
4. The professional CNC pipe cutting system is easy and simple to operate and maintain.
5. Integrated large air volume dust removal system.
6. Imported high-end accessories to provide users with powerful cutting ability and efficiency, ensuring high-precision and stable operation of the machine.


Main Parts Of Fiber Laser Tube Cutting Machine

Double Pneumatic Automatic Chuck

Electric clamp design is adopted on both sides, one-click opening of the clamp, automatic worry-free, the speed is 3 times that of the electric chuck, reducing the waiting time for loading and unloading;Pneumatic clamping, large and stable clamping force, no loosening or slipping of heavy pipes, ensuring cutting accuracy;

Dedicated Support Frame

The use of smart tube bracket design can solve the problem of deformation during the cutting of long tubes, improve cutting accuracy and extend the service life of the chuck.

The base frame of our laser cut sheet metal machine is welded by heavy steel. After a series of production steps, our machine frame will not get deformed for long time use. And this is the process of how to make our CNC pipe laser cutting machine frame:Using the thick steel pipe to weld the machine frame→ Annealing process→ Rough machining→ Vibratory Stress Relief → Fine machining.

So you can use this laser tube cutting machine to process almost every materials.

The gantry beam of this pipe laser cutting machine is made of aviation aluminum, the aerospace aluminum was manufactured using aerospace standards and extruded using a 4,300 ton press. After the aging treatment, the hardness can reach T6, which is the strongest of all beams.it has many advantages such as good toughness, light weight, corrosion resistance, oxidation resistance and low density.So It can greatly improve the work effiency of this CNC laser metal cut pipe machine.

  • Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time;
  • Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced;
  • Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns;

This is the Max fiber laser generator,Max as a famous fiber laser manufacturer,its product quality is reliable.And it has many advantages,such as it has an extremely high electro-optic conversion efficiency,excellent stability and excellent single mode beam quality.Meanwhile,it price is not high and it can direct the modulation range kHZ and it can Stable beam quality in the full power range.

Tube&Plate Sheet Metal Laser Cutting Machine

Parameters

Model iGR-FT
Fiber Laser MAX / JPT
Control System Shanghai Cypcut
Servo motor Japan Yaskawa
Cutting head RayTools
Gantry Aviation aluminum beam
Guide rail Taiwan T-WIN square rail
Rack&pinion Taiwan T-WIN famous brand
Water chiller HanLi
Proportional valve Japan SMC
Electronics France Schneider
Voltage Three-phase 380V 50/60Hz

Sheet and Tube Fiber Laser Cutter Application Material:

Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting like stainless steel sheet and tube, mild steel plate and tube, carbon steel sheet and tube, alloy steel plate and tube, spring steel sheet and tube, iron plate and tube, galvanized iron and tube, galvanized sheet and tube, aluminum plate and tube, copper sheet and tube, brass sheet and tube, bronze plate and tube, gold plate and tube, silver plate and tube, titanium plate and tube, metal sheet and tube, metal plate and tube, etc.

Tube and Sheet Laser Cutter Application Industries:

Fiber Laser Cutting Machines are widely used in manufacture billboard, advertising, signs, signage, metal letters, LED letters, kitchen ware, advertising letters, sheet metal processing, metals components and parts, ironware, chassis, racks & cabinets processing, metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, glasses frame, electronic parts, nameplates, refrigeration machinery, agricultural machinery, food machinery, kitchen stainless steel countertops, aerospace, railroad locomotive, auto parts manufacturing, car body processing, medical equipment, smart home, home appliances, kitchen equipment, fitness equipment, machinery manufacturing, sheet metal processing. etc.

tube laser cutting
sheet metal cutting

Metal Laser Cutting Machines


Fiber Laser Cutters

Fiber laser cutting has many advantages compared with traditional cnc metal cutting solutions. Advantages mainly include: higher cutting precision and accuracy, higher quality cut edge, narrower incision width, smaller heat affected zone, less material deformation, less material pollution and waste, lower maintenance and repair costs, and higher operator safety. Compared with the traditional cnc metal sheet and tube cutting machine, fiber laser cutter can deal with various designs with higher precision and efficiency. Completely controlled by CNC, fiber laser metal cutting machine can produce complex parts with high tolerance repeatedly and consistently. Laser cutting can also produce high quality cut edges, usually without further cleaning, processing or finishing, thus reducing the need for secondary processing. IGOLDEN laser, as leading manufacturer and supplier of fiber laser machines in China, will provide best quality and factory price laser cutting machine for metal sheets and tubes, including stainless steel, carbon steel, aluminium, copper, galvanized sheet, mild steel, corten steel, silver, gold, ect.



CO2 laser cutting machine

A CO2 laser cutter is a professional automatic laser engraving and cutting system using a 1064μm laser beam from the CO2 glass laser tube to etch and cut wood, MDF, plywood, paper, leather, fabric, textile, resin, plastic, acrylic, rubber, crystal, glass, ceramics, stone, and more non-metallic materials. It relies on the laser power to drive the carbon dioxide gas laser tube to emit laser beam, with reflectors, the beam is transmitted to the laser head, and then the focusing mirror converges the beam on a point, and this point can reach a very high temperature, thus the excess material is instantly sublimated into gas, which is sucked away by the exhaust fan, so as to create a laser-cut project. CO2 laser cutting machines are used to engrave and cut in clothing, fashion, garment, shoes, bags, toys, embroidery, electronic appliances, molds, models, arts, crafts, advertising, decorations, packaging, and printing.
